Modular Aluminum Stage Truss for Events 500kg Capacity

  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
  • Modular Aluminum Stage Truss for Events 500kg Capacity
Lugar de origen Jiangsu, China
Nombre de la marca Shizhan
Número de modelo Truss-rt de aluminio
Cantidad de orden mínima 100
Precio $44-46

Éntreme en contacto con gratis las muestras y los vales.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Tipo de conexión Conexión de PIN Capacidad de carga 500 kg
Material Aleación de aluminio Duración de la unidad los 0.5m, el 1m, los 2m, 3M, los 4m, los 5m o modificado para requisitos particulares
Trusa cuadrado, triángulo, ronda o modificado para requisitos particulares Forma de la sección de la armadura Cuadrado o redondo
Espesor del tubo de truss 1.5/2/3 mm Diámetro del tubo de truss 20 mm, 32 mm, 50 mm
Dureza 16 grados Truss de servicio ligero Las medidas siguientes se aplicarán:
Truss de servicio medio 290*290 mm, 300*300 mm; 350*350 mm, 300*400 mm; 400*400 mm; 450*450 mm; 400*600 mm trampolín de trabajo pesado 520*760 mm; 600*760 mm; 600*1000 mm
Espesor del tubo principal 30*2 mm; 50*3 mm; 50*4 mm; 50*5 mm Espesor de vicio El valor de las emisiones de gases de efecto invernadero es el valor de las emisiones de gases de ef
Espesor del tubo de abrazadera Las medidas siguientes se aplicarán:
Resaltar

modular aluminum stage truss

,

aluminum lighting truss 500kg capacity

,

event truss with high load capacity
Deja un mensaje
Descripción de producto
Aluminium Stage Truss Structure Outdoor Stage Truss Design
Product Specifications
Attribute Value
Connection Type Pin Connection
Feature Durable
Frame design Modular
Product Type Display Truss
Application Events, Concert, Music, Performance, DJ Band, Event, Exhibition
Welding Welding
Load-bearing Capacity 500kg
Assembly Method Quick installation
Structure Type Modular Structure
Material Aluminum alloy
Unit length 0.5m, 1m, 2m, 3m, 4m, 5m or customized
Color Silver, black or customized
Truss section shape Square or round
Shape Square, Triangle, round or customized
Truss tube thickness 1.5/2/3MM
Truss tube diameter 20mm, 32mm, 50mm
Hardness 16 degree
Modular Aluminum Stage Truss for Events 500kg Capacity 0 Modular Aluminum Stage Truss for Events 500kg Capacity 1
Technical Details
Truss Material: Aluminum alloy 6082-T6
Light duty truss: 200*200mm; 250*250mm
Medium duty truss: 290*290mm, 300*300mm; 350*350mm; 300*400mm; 400*400mm; 450*450mm; 400*600mm
Heavy duty truss: 520*760mm; 600*760mm; 600*1000mm
Main tube thickness: 30*2mm; 50*3mm; 50*4mm; 50*5mm
Vice tube thickness: 18*2mm; 20*2.5mm; 25*2.5mm
Brace tube thickness: 20*2mm; 25*2mm; 30*2mm
Length: 0.5m/1m/1.5m/2m...4m or custom size
Truss type: Spigot or bolt
Truss Shape: Ladder truss, triangular truss, square truss, arch truss, circle truss
Color: Silver or black, blue, green...
Usage: Concert, new product release, fashion show, booth stand construction
Delivery Time: 10 working days
Modular Aluminum Stage Truss for Events 500kg Capacity 2 Modular Aluminum Stage Truss for Events 500kg Capacity 3 Modular Aluminum Stage Truss for Events 500kg Capacity 4 Modular Aluminum Stage Truss for Events 500kg Capacity 5
Applications
Our aluminum alloy stage truss is a modular system made of lightweight aluminum alloy tubes that can be easily assembled and disassembled. It is widely used in various events and applications:
  • Concerts and festivals: Build stages for concerts, festivals, and outdoor events with configurable shapes and sizes
  • Theatrical productions: Construct sets, backdrops, and structures for plays, musicals, and operas
  • Exhibitions and trade shows: Create booths, displays, and exhibition structures
  • Corporate events: Build stages and backdrops for product launches, conferences, and award ceremonies
  • Sports events: Construct race start/finish lines, podiums, and scoreboards
Modular Aluminum Stage Truss for Events 500kg Capacity 6 Modular Aluminum Stage Truss for Events 500kg Capacity 7 Modular Aluminum Stage Truss for Events 500kg Capacity 8 Modular Aluminum Stage Truss for Events 500kg Capacity 9 Modular Aluminum Stage Truss for Events 500kg Capacity 10 Modular Aluminum Stage Truss for Events 500kg Capacity 11
Why Choose Our Products
  • TUV, SGS, CE Certified products
  • 15 years experience in truss, stage, barrier and scaffolding
  • 35,000 m² workshop with excellent production capacity
  • Professional engineering team for perfect project solutions
  • Own aluminum profile production line for quality control
  • Strict QC process with installation test before delivery
Frequently Asked Questions
How do I know your quality? Our products have TUV/SGS/CE/ISO9001 certificates and we offer samples for quality checking.
Payment methods: T/T, Western Union, Trade Assurance, L/C.
Warranty: 1 year warranty with free replacement for non-artificial damage.
Customization: Our technical team offers perfect solutions for custom projects.
Modular Aluminum Stage Truss for Events 500kg Capacity 12
