Aluminum Spigot Truss for Stage Events 500kg Load Capacity

  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
  • Aluminum Spigot Truss for Stage Events 500kg Load Capacity
Lugar de origen Jiangsu, China
Nombre de la marca Shizhan
Número de modelo Truss-rt de aluminio
Cantidad de orden mínima 100
Precio $44-46

Éntreme en contacto con gratis las muestras y los vales.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Tipo de conexión Conexión de PIN Material Aleación de aluminio 6082-T6
Capacidad de carga 500 kg Duración de la unidad los 0.5m, el 1m, los 2m, 3M, los 4m, los 5m o modificado para requisitos particulares
Trusa Cuadrado, redondo, triángulo, rectángulo o personalizado Forma de la sección de la armadura Cuadrado o redondo
Espesor del tubo de truss 1.5/2/3 mm Diámetro del tubo de truss 20 mm, 32 mm, 50 mm
Dureza 16 grados Tamaño de servicio ligero Las medidas siguientes se aplicarán:
Tamaño de servicio medio 290*290 mm, 300*300 mm; 350*350 mm, 300*400 mm, 400*400 mm, 450*450 mm, 400*600 mm Tamaño de servicio pesado 520*760 mm; 600*760 mm; 600*1000 mm
Espesor del tubo principal 30*2 mm; 50*3 mm; 50*4 mm; 50*5 mm Espesor de vicio El valor de las emisiones de gases de efecto invernadero es el valor de las emisiones de gases de ef
Espesor del tubo de abrazadera Las medidas siguientes se aplicarán:
Resaltar

aluminum spigot truss 500kg capacity

,

stage event truss aluminum spigot

,

aluminum lighting truss heavy duty
Deja un mensaje
Descripción de producto
Aluminum Spigot Stage Event Truss
Product Specifications
Connection Type Pin Connection
Feature Quick installation
Shape Rectangle, square, Triangle, round or customized
Frame design Square
Product Type Display Truss
Application Exhibitions, Concert, Music, Performance, DJ Band, Event, Exhibition
Material Aluminium, aluminum alloy
Welding Welding
Load-bearing Capacity 500kg
Assembly Method Quick installation
Structure Type Modular Structure
Unit length 0.5m,1m,2m,3m,4m,5m or customized
Color Silver, black or customized
Truss section shape Square or round
Truss tube thickness 1.5/2/3MM
Truss tube diameter 20mm,32mm,50mm
Hardness 16 degree
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 0
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 1
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 2
Technical Details
Truss Material Aluminum alloy 6082-T6
Light duty truss 200*200mm; 250*250mm
Medium duty truss 290*290mm,300*300mm; 350*350mm
300*400mm; 400*400mm; 450*450mm; 400*600mm
Heavy duty truss 520*760mm; 600*760mm; 600*1000mm
Main tube thickness 30*2mm; 50*3mm; 50*4mm; 50*5mm
Vice tube thickness 18*2mm; 20*2.5mm; 25*2.5mm
Brace tube thickness 20*2mm; 25*2mm; 30*2mm
Length 0.5m/1m/1.5m/2m...4m or custom size
Truss type Spigot or bolt
Truss Shape Ladder truss, triangular truss, square truss, arch truss, circle truss
Color Silver or black, blue, green...
Usage Concert, new product release, fashion show, booth stand construction
Delivery Time 10 working days
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 3
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 4
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 5
Applications
  • Concerts and festivals: Build stages for outdoor events with various configurations and accessories
  • Theatrical productions: Create sets, backdrops, and structures for plays and musicals
  • Exhibitions and trade shows: Construct booths and displays for product showcases
  • Corporate events: Build professional stages for product launches and conferences
  • Sports events: Create structures for race lines, podiums, and scoreboards
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 6
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 7
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 8
Company Advantages
  • TUV, SGS, CE Certified products
  • 15 years experience in truss and stage manufacturing
  • 35,000 m² workshop with strong production capacity
  • Professional engineering team for project solutions
  • Own aluminum profile production line for quality control
  • Strict QC process with installation testing before delivery
Frequently Asked Questions
Why should I choose your company instead of other suppliers?

We offer certified products with 15 years of experience, large production capacity, professional engineering support, and strict quality control processes.

How do I know your quality? Do you support sample orders?

Our products have TUV/SGS/CE/ISO9001 certificates. We can provide samples for quality checking before batch orders.

Which kinds of payment does your company accept?

We accept T/T, Western Union, Trade Assurance, and L/C payments.

What is your products warranty time?

Our standard warranty is one year, covering any non-artificial damage with free replacements.

Can you do customized design?

Yes, our technical team provides perfect solutions for custom project requirements.

Aluminum Spigot Truss for Stage Events 500kg Load Capacity 9
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 10
Aluminum Spigot Truss for Stage Events 500kg Load Capacity 11
